#2: The matrix program verifies

What it took

Our model is currently asymmetrical in the way it represents alloc and dealloc operations, meaning that dealloc statements can only be verified after an alloc statement has been executed. This poses a problem for verifying "destructors", i.e. functions that free memory given to them in an argument, because we have no way of indicating the assumption of previous allocation. To work around this we've introduced a kind of precondition capability, in which one labels "set-up" statements in the abstract with the tag pre; these are then executed in the verification process prior to either the body of the function or its abstract (during the abstract verification phase).
We've been running into trouble when verifying functions like
```
struct matrix *
matrix_create(unsigned int rows, unsigned int cols);
```
because we can't be sure that rows and cols are nonzero. This means that if we do a range of allocations over the interval 0:rows, it is possible that this interval is empty, in which case no allocations would take place. This creates a problem during deallocation (of the range) because until now our logic has involved searching for the objects (in the block containing the range) that include the lower- (here 0) and upper-bound (rows) of the range, and then resizing the objects at the bounds and deallocating all the ones in between them. If 0:rows, however, proves to be empty, then neither 0 nor rows will be in it, invalidating our approach despite the propriety of "recognising" that all the allocated memory in this potentially-empty range has been freed.

As a hack we've hardcoded in the case where there is only one object (0:rows) in the block we're analysing, which happens to be the only case that obtains for our matrix_destroy currently, and this allowed us to close off the iteration.
There's one or two (or 55kB worth of) leaks.

If only there was some kind of tool for this :)

Next up

The work on Xr0 continues.

Our goal for the next couple of months is to get a more sizeable program verified with Xr0, and we'll be sharing more about this soon.

The coming iteration (to 16th) will be focused on refactoring and attempting to refine the codebase, isolating the "essence" of what is required to verify the matrix program. We regard this as a necessary next step because the codebase is now at 6800 LOC and a lot of hacks (and leaks) have accrued, not to mention confusion across our layers of abstraction.

Our goals for this iteration:

We will eliminate at least 75% of the leaks [#4]
We will eliminate EXPR_ACCESS converging to pointer-based representations [#5]
The concepts of a value and variable are very similar in our model: we will attempt to converge them [#6]
We will make the execution paths involving lvalues and rvalues consistent and remove resolve_bounds [#7]
We will refactor the state to remove the re-declarations of its submodules in its header file [#8]
We will investigate a symmetric allocation/deallocation paradigm for at least three days [#9].
